The Night Rod® Special offers a raw, street-tough attitude, with an all-black Revolution V-Twin engine and blacked-out fork legs, swing arm and other components. The speed-screen visor and racing stripe come straight from the drag strip.
The VRSC™ family offers an unmatched combination of style and performance. The 60-degree Revolution 1250 cc V-Twin is liquid-cooled and features Electronic Sequential Port Fuel Injection (ESPFI), dual overhead cams, four-valve heads, and a five-speed transmission.
The engine is rubber-mounted in a hydroformed steel perimeter frame. A shell covers the large-volume airbox located over the engine. A five-gallon fuel cell is located below the seat on all VRSC models.
Model Highlights
• Black powder-coated powertrain with black covers
• Straight-shot exhaust with brushed finish dual mufflers with black end caps and exhaust shield
• Black, Slotted Disc Cast Aluminum wheels with orange pin stripe
• Sport front fender with black brace supports
• Color-matched speed screen visor
• Stainless steel, low-rise drag-style handlebar
• Black mirrors, rear shocks and controls
• Black frame
• Two-piece, two-up textured seat
• Contrasting racing stripe paint scheme
• Black powder-coated powertrain with black covers
• Straight-shot exhaust with brushed finish dual mufflers with black end caps and exhaust shield
• Black, Slotted Disc Cast Aluminum wheels with orange pin stripe
• Sport front fender with black brace supports
• Color-matched speed screen visor
• Stainless steel, low-rise drag-style handlebar
• Black mirrors, rear shocks and controls
• Black frame
• Two-piece, two-up textured seat
• Contrasting racing stripe paint scheme
Key Features of The Night Rod® Special offers a raw, street-tough attitude, with an all-black Revolution V-Twin engine and blacked-out fork legs, swing arm and other components. The speed-screen visor and racing stripe come straight from the drag strip.
The VRSC™ family offers an unmatched combination of style and performance. The 60-degree Revolution 1250 cc V-Twin is liquid-cooled and features Electronic Sequential Port Fuel Injection (ESPFI), dual overhead cams, four-valve heads, and a five-speed transmission.
The engine is rubber-mounted in a hydroformed steel perimeter frame. A shell covers the large-volume airbox located over the engine. A five-gallon fuel cell is located below the seat on all VRSC models.
• High-performance Brembo® triple-disc brakes
• Race-bred clutch with “slipper” action helps ease drive train effort during downshifting
• 240 mm wide rear tire
• Forward-mounted footpegs and controls
• Round reflector-optic headlight
• Electric power accessory connector under seat
• Optional, factory-installed Anti-Lock Braking System (ABS)
• Optional Harley-Davidson® Smart Security System with hands-free security fob
Harley-Davidson VRSCDX Night Rod Special Specifications
DIMENSIONS
ENGINE
• Rotor Type (diameter x width): Patented, one-piece floating rotor (front), uniform expansion rotor (rear)
• Front (dual) 11.81 in. x .2 in. (300 mm x 5 mm)
• Rear 11.81 in. x .28 in. (300 mm x 7 mm)
• ABS Option Available
Suspension Travel:
• Front 4 in. (102 mm)
• Rear 2.9 in. (74 mm)
• North America 85 ft. lbs. @ 7000 RPM (115 Nm @ 7000 RPM)
Lean Angle (per SAE J1168):
• Right 32°
• Left 32°
Fuel Economy6
(EPA urban/highway test)
34/42 mpg (6.92/5.60 L/100 km)
Length 94.4 in. (2398 mm)
Overall Width 34.6 in. (879 mm)
Overall Height 45.5 in. (1156 mm)
Seat Height:
• Laden2 25.2 in. (640 mm)
• Unladen 26.3 in. (668 mm)
Ground Clearance 4.2 in. (107 mm)
Rake (steering head) 34°
Fork Angle 36°
Trail 4.5 in. (114 mm)
Wheelbase 67.2 in. (1707 mm)
Tires (Michelin® Scorcher™ “11” front and rear):
• Front – Scorcher™ “11” 120/70ZR-19 60W
• Rear – Scorcher™ “11” 240/40R-18 79V
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 0.5 gal.)
Oil Capacity (w/filter) 5.0 qts. (4.7 L)
Coolant Capacity 2.5 qts. (2.4 L)
Weight:
• As Shipped 643 lbs. (292.0 kg)
• In Running Order 676 lbs. (307.0 kg)
• Gross Vehicle Weight Rating 1075 lbs. (488.0 kg)
• Gross Axle Weight Rating
• Front 377 lbs. (171.0 kg)
• Rear 698 lbs. (317.0 kg)
Overall Width 34.6 in. (879 mm)
Overall Height 45.5 in. (1156 mm)
Seat Height:
• Laden2 25.2 in. (640 mm)
• Unladen 26.3 in. (668 mm)
Ground Clearance 4.2 in. (107 mm)
Rake (steering head) 34°
Fork Angle 36°
Trail 4.5 in. (114 mm)
Wheelbase 67.2 in. (1707 mm)
Tires (Michelin® Scorcher™ “11” front and rear):
• Front – Scorcher™ “11” 120/70ZR-19 60W
• Rear – Scorcher™ “11” 240/40R-18 79V
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 0.5 gal.)
Oil Capacity (w/filter) 5.0 qts. (4.7 L)
Coolant Capacity 2.5 qts. (2.4 L)
Weight:
• As Shipped 643 lbs. (292.0 kg)
• In Running Order 676 lbs. (307.0 kg)
• Gross Vehicle Weight Rating 1075 lbs. (488.0 kg)
• Gross Axle Weight Rating
• Front 377 lbs. (171.0 kg)
• Rear 698 lbs. (317.0 kg)
ENGINE
Engine3 Liquid-cooled, Revolution®, 60° V-Twin
Valves Overhead cam, 4 valves per cylinder, solid tappet with shim-under-bucket lash adjustment
Bore x Stroke 4.134 in. x 2.835 in. (105 mm x 72 mm)
Displacement 76.28 cu. in. (1250 cc)
Compression Ratio 11.5:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Down draft intake
Lubrication System Wet-sump, integrated with
powertrain crankcase
DRIVETRAINValves Overhead cam, 4 valves per cylinder, solid tappet with shim-under-bucket lash adjustment
Bore x Stroke 4.134 in. x 2.835 in. (105 mm x 72 mm)
Displacement 76.28 cu. in. (1250 cc)
Compression Ratio 11.5:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Down draft intake
Lubrication System Wet-sump, integrated with
powertrain crankcase
Primary Drive Gear, 117/64 ratio
Final Drive Belt, 72/28 ratio
Clutch 9-plate, wet, A&S (Assist & Slip)
Transmission 5-speed
U.S. Gear Ratios (overall):
• 1st 11.752
• 2nd 7.898
• 3rd 6.322
• 4th 5.459
• 5th 4.899
Swingarm Polished, one-piece cast aluminum with black powder-coat finish
Front Forks Wide, 49 mm custom
Rear Shocks Preload adjustable
Wheels4: Black, Slotted Disc Cast Aluminum
• Front 19 in. x 3 in. (483 mm x 76 mm)
• Rear 18 in. x 8 in. (457 mm x 203 mm)
Final Drive Belt, 72/28 ratio
Clutch 9-plate, wet, A&S (Assist & Slip)
Transmission 5-speed
U.S. Gear Ratios (overall):
• 1st 11.752
• 2nd 7.898
• 3rd 6.322
• 4th 5.459
• 5th 4.899
CHASSIS
Frame Steel perimeter upper frame with hydroformed main rails and bolt-on lower frame rails; MIG weldedSwingarm Polished, one-piece cast aluminum with black powder-coat finish
Front Forks Wide, 49 mm custom
Rear Shocks Preload adjustable
Wheels4: Black, Slotted Disc Cast Aluminum
• Front 19 in. x 3 in. (483 mm x 76 mm)
• Rear 18 in. x 8 in. (457 mm x 203 mm)
BRAKES
• Caliper Type 4-piston front and rear• Rotor Type (diameter x width): Patented, one-piece floating rotor (front), uniform expansion rotor (rear)
• Front (dual) 11.81 in. x .2 in. (300 mm x 5 mm)
• Rear 11.81 in. x .28 in. (300 mm x 7 mm)
• ABS Option Available
Suspension Travel:
• Front 4 in. (102 mm)
• Rear 2.9 in. (74 mm)
PERFORMANCE
Engine Torque5 (per SAE J1349):• North America 85 ft. lbs. @ 7000 RPM (115 Nm @ 7000 RPM)
Lean Angle (per SAE J1168):
• Right 32°
• Left 32°
Fuel Economy6
(EPA urban/highway test)
34/42 mpg (6.92/5.60 L/100 km)
Harley-Davidson Night Rod Special VRSCDX is worth for $16,699
Official website about Harley-Davidson Night Rod Special VRSCDX
